Large Caliber Prepaid IC Card Water Meter ISO 4064 Contactless Brass Factory Price IP68 Protection Horizontal OEM Customizable

Large Caliber Prepaid IC Card Water Meter ISO 4064 Contactless Brass Factory Price IP68 Protection Horizontal OEM Customizable

  • Large Caliber Prepaid IC Card Water Meter ISO 4064 Contactless Brass Factory Price IP68 Protection Horizontal OEM Customizable
  • Large Caliber Prepaid IC Card Water Meter ISO 4064 Contactless Brass Factory Price IP68 Protection Horizontal OEM Customizable
  • Large Caliber Prepaid IC Card Water Meter ISO 4064 Contactless Brass Factory Price IP68 Protection Horizontal OEM Customizable
  • Large Caliber Prepaid IC Card Water Meter ISO 4064 Contactless Brass Factory Price IP68 Protection Horizontal OEM Customizable
  • Large Caliber Prepaid IC Card Water Meter ISO 4064 Contactless Brass Factory Price IP68 Protection Horizontal OEM Customizable
  • Large Caliber Prepaid IC Card Water Meter ISO 4064 Contactless Brass Factory Price IP68 Protection Horizontal OEM Customizable
  • Large Caliber Prepaid IC Card Water Meter ISO 4064 Contactless Brass Factory Price IP68 Protection Horizontal OEM Customizable
Large Caliber Prepaid IC Card Water Meter ISO 4064 Contactless Brass Factory Price IP68 Protection Horizontal OEM Customizable
Product Details:
Place of Origin: Hunan, China
Brand Name: ChangDe
Model Number: LXSLK-40-200
Contact Now
Detailed Product Description
Warranty: 1 Year Customized Support: OEM, ODM, OBM
Flow Rate: Q3=40m3/h Measurement Range: R80 R100 R160
Type: Multi-jet Meters, Prepaid Water Meters, Turbine Meters Material: Copper,castiron
Connectivity: FLANGED Protection Class: Ip68
Product Name: RF Card Water Meter Smart Water Meter With Brass Valve Waterproof: IP68
Normal Size: 40~200mm Material: Brass
Water Temperature: 0.1~30℃ Working Pressure: ≤1MPa
Standard: ISO4064 ISO9001:2008 Installation: Horizontal

Big Caliber RF IC Card  Intelligent Prepaid Smart Water Meter With Brass Valve Control Water Flow Meter Factory Directly Supply



Product Description

 Large Caliber Prepaid IC Card Water Meter ISO 4064 Contactless Brass Factory Price IP68 Protection Horizontal OEM Customizable 0



Product Features:



  1. All copper base meter: stable metering performance, no rust safety and hygiene, clear reading;
  2. IP68 waterproof grade: adopt structural seal design, seal performance reaches IP68, can work normally in wet environment;
  3. Contact-less IC card: wireless self-seeking card technology, wireless transmission of data, safe and reliable;
  4. Step water price function: support monthly, annual price, user card update ladder water price parameters;
  5. Valve maintenance function: timing switch valve, prevent valve scaling;
  6. Abnormal valve function: detection of battery power down, low voltage, sensor fault automatically turn off the valve, liquid crystal screen display failure code;
  7. Battery replacement function: the user can replace the battery by himself and brush the user card opening valve after replacing the battery;
  8. Data retrieval function: the user card can bring back the water information and status word in the meter;
  9. Disconnection valve function: after unplugging the communication cable, the valve automatically closes (split card meter)
  10. Support real-time charging network, set up a number of charging sites, users can pay in the latest toll site. At the same time, can provide interface functions, seamless docking with third parties;
  11. The client supports the online upgrade function. After the charging computer is connected, the user can update the client charging system through the remote server when the software starts;
  12. Blacklist query function: query abnormal payment of customers, easy to management audit;
  13. Property fee collection function: according to the area or time to collect property fees;
  14. Custom invoice format: customers can customize the bill format according to their own needs.
  15. Permission setting function: assign, set the administrator's permission, easy to manage the system.







  1. Main Tech. Parameters



Large Caliber Prepaid IC Card Water Meter ISO 4064 Contactless Brass Factory Price IP68 Protection Horizontal OEM Customizable 2





Large Caliber Prepaid IC Card Water Meter ISO 4064 Contactless Brass Factory Price IP68 Protection Horizontal OEM Customizable 4Large Caliber Prepaid IC Card Water Meter ISO 4064 Contactless Brass Factory Price IP68 Protection Horizontal OEM Customizable 6Large Caliber Prepaid IC Card Water Meter ISO 4064 Contactless Brass Factory Price IP68 Protection Horizontal OEM Customizable 8Large Caliber Prepaid IC Card Water Meter ISO 4064 Contactless Brass Factory Price IP68 Protection Horizontal OEM Customizable 10Large Caliber Prepaid IC Card Water Meter ISO 4064 Contactless Brass Factory Price IP68 Protection Horizontal OEM Customizable 12Large Caliber Prepaid IC Card Water Meter ISO 4064 Contactless Brass Factory Price IP68 Protection Horizontal OEM Customizable 14
