NB-IoT water meter

NB-IoT water meter is a new remote water meter based on GPRS network or NB-IoT network. NB-IoT water meter adopts the special network communication, the data communication is safe and reliable.

Product Feature:

Convenient maintenance: Structural design of electromechanical separation, easy installation on site and convenient maintenance

Installed easily:  it can be installed wherever there is a cell phone signal.

Long time battery life: 6 years

 Main Function:

Transmitted safely and reliably: GPRS & NB-IoT

Double Hall sensor: realize the forward and backward metering of water meter, ensure the complete synchronization of electromechanical, and there is no accumulative error.

Monitor in real time: Monitor magnetic interference, low voltage battery, upload abnormal alarm to meter reading platform.

Main Technical Data:

Standard Compliance:

• GB/T 778.1-2007/ISO4064-1:2005

  Working Conditions:

• Water temperature: lower than 30°C (T50 as option)

• Working pressure: 10 bar (16 bar as option)

  Permissible Error Value and Error curve

• Max. Permission Error (for T30): From Q1 inclusive up to but excluding Q2 is ± 5%;

• From Q2 inclusive up to and including Q4 is ± 2%;when water temperature is >30oC,it will be ± 3%.

•
•
