Name: NB-IoT Wireless Remote Reading Water Meter with Customized Local SIM Card and Band Frequency Water Meter
Brand: Hunan Changde Water Meter Manufacture Co., Ltd.
SKU: LXSW-15~25
Availability: InStock

Home Products GPRS,NB-IOT water meter

NB-IoT Wireless Remote Reading Water Meter with Customized Local SIM Card and Band Frequency Water Meter

Product Details:

Place of Origin:	Hunan, China
Brand Name:	Changde
Model Number:	LXSW-15~25

Contact Now

Detailed Product Description

Warranty:	1 Year, 1 Year	Customized Support:	OEM
Flow Rate:	2.5-6.3m3/h	Measurement Range:	R100
Type:	Multi-jet Meters	Connectivity:	Threaded
Protection Class:	Ip68	Name:	NB-IOT Smart Water Meter Iso 4064
Material:	Brass	Type Name:	Wireless Transmission Remote Reading Cold Water Meter
Certificate:	ISO4064 ISO9001:2015	Installation:	Horizontal
Water Temperature:	≤30℃	Working Pressure:	≤1MPa
Normal Size:	15mm~25mm

NB-IoT wireless remote reading water meter with customized local SIM card and band frequency water meter

NB-IoT water meter is a new remote water meter based on GPRS network or NB-IoT network. NB-IoT water meter adopts the special network communication, the data communication is safe and reliable.Structural design of electromechanical separation, easy installation on site and convenient maintenance, it can be installed wherever there is a cell phone signal.

Product Features:
Transmit through NB-IoT private network, safe and stable
Easy maintenance & replacement, adopts electrical & mechanical separation structure design
Double protection with integral structure seal and glue filling seal
Built-in high-capacity lithium battery, battery life is more than 6 years
Remote setting function set up data upload time and interval remotely

Diameter(DN)mm	15		20		25
Overload flow rate (Q4)m³/h	3.125		5		7.785
Normal flow rate (Q3)m³/h	2.5		4		6.3
Transitional flow rate (Q2)m³/h	0.05/0.04		0.08/0.064		0.126/0.1
Min. flow rate (Q1)m³/h	0.032/0.025		0.05/0.04		0.078/0.063
Measure Range(Q3/Q1)		80/100
Measurement grade		Level 2
Frequency		470-510Mhz/800Mhz
Working pressure		≤1.0 MPa
Pressure loss		P63(≤0.063M Pa)
Operating Temp.		Cold water (T50):0.1℃~50℃		Hot water (T90):0.1℃~90℃
Flow profile sensitivity grade		U10,D5
Climate & mechanical environmental safety		Class B
Electromagnetic compatibility level		E1
Quiescent current		≤25uA
Working Voltage		3.6V lithium battery
Waterproof Level		IP68
